Furnace Control Circuit Board for 240 VAC Inducer Motor: 4A, FLA-8.0 LRA at 120 VAC, Replacement for Carrier Modules HK42FZ016, HK42FZ034, 325878-751. from Acupress

Specification: Range: 98 to 132 VAC at 60 Hz Ignitor: 5A at 120 VAC Cool Blower: 30A, 2 HP,240 VAC Heat: 5A, 1/2 HP, 240 VAC Inducer Motor: 4A, FLA-8.0 LRA at 120 VAC Gas Valve Compatible Models: for 24 VAC standard thermostat for Carrier modules:CEBD431012-01A, CEPL1311012-01, HK42FZ004, HK42FZ007, HK42FZ008, HK42FZ009, HK42FZ011,HK42FZ013, HK42FZ016, HK42FZ034, 325878-751 Features: Controls gas valve, ignitor, blower motor, inducer, humidifier and air cleaner Microprocessor-based, designed for shutoff in case of ignition failureReverse polarity protection, secondary brownout voltage protection ,provides diagnostic LED to aid in troubleshooting Package Includes: 1x Furnace Control Board___________________________Buy with BRAND - Acupress, be sure of q-uality.

• Range: 98 to 132 VAC at 60 Hz Ignitor: 5A at 120 VAC. Cool Blower: 30A, 2 HP,240 VAC Heat: 5A, 1/2 HP, 240 VAC Inducer Motor: 4A, FLA-8.0 LRA at 120 VAC Gas Valve
• Fitment: This furnace control circuit board fixed speed furnace control replaces the for following Carrier modules:CEBD431012-01A, CEPL1311012-01, HK42FZ004, HK42FZ007, HK42FZ008, HK42FZ009, HK42FZ011,HK42FZ013, HK42FZ016, HK42FZ034, 325878-751
• Warm Note: Software for enhanced controls operation in counterflow and downflow furnace applications.Use caution when installing and servicing the furnace to avoid and control electrostatic discharge
• Function: Reverse polarity protection, secondary brownout voltage protection, fits for a 24 VAC standard thermostat ,provides diagnostic LED to aid in troubleshooting; Package Includes: 1x furnace control circuit board as pictured
• 【Important】If the product is defective or damage upon arrival, or if you don't want it any more, or the product cannot fix your issue, please contact us immediately, we will provide assist to solve the problem ASAP
